TPS have been supplying innovative and reliable drives and fuel pump motor controllers for the Boeing 787 Dreamliner for over a decade

We are an AS9100 certified supplier of innovative drives and fuel pump motor controllers for the aerospace industry. To date, we have supplied over 2000 fuel pump motor controllers for the Boeing 787 Dreamliner. Two of our motor controllers are installed on each aircraft in the DC rack in the aft equipment bay and are responsible for the transfer of fuel from the centre fuel tank to the wings during take-off.

Our unique flight certified motor controller drives are liquid-cooled and lightweight offering an ideal low footprint solution. To ensure optimum operational uptime we conduct arduous testing to ensure our product can withstand the harsh environments they face whilst installed on the aircraft.

TPS Solutions for Aerospace

Specification Overview:

  • DC Input Voltage  480 to 640 Vdc
  • AC Output Voltage  3-phase 320 Vac (17 A, 363 Hz)
  • AC Output Power  9.4 kVA @ 0.8 pf (7.5 kW)
  • Efficiency  94%
  • Weight  7.4 kg
  • Dimensions  440 x 160 x 160 mm
